Escort Railways Product

Machined Components

DISC BRAKE ITEMS

HEADER – 2
HEADER – 1
BRACKE 1/4
BRACKET 3/8
BRACKET 3/4
WHISTLE
JUMPER PLATE
BRACKET FOR PR. SWITCH
HOUSING
ROLLER ARM
BRACKET 2 FOR ROPE
FORK PIECE
TIGHTENING TOOL

SIDE PLATE
SPECIAL RING SPANNER

BRAKE ITEMS

SIDE SUPPORT (2 TYPES)
FLANGE FOR SAFETY VALVE
ADAPTOR FOR PR SENSOR
FLANGE FOR SAFETY VALVE
FLANGE -1

BASE PLATE
BRACKET
SOCKET BP(2 TYPES)
SOCKET BC(2 TYPES)
SOCKET MR & AR (2 TYPES)
INSULATING PIECE
BRACKET PRV
SPACER (3 TYPES)
TERMINAL COVER
BLANK PLATE
BOTTOM FLANGE(2 TYPES)
UPPER SUPPORT
STOPPER PIECE
BRACKETS (3 TYPES)
BOTTOM FLANGE (2 TYPES)

S.N.	Instrument / Gauge Name	Instrument/Gauge-ID	Range	Least Count	Make
1	Digital Vernier Caliper	DVC-01	0-150 MM	0.01MM	Insize
2	Digital Vernier Caliper	DVC-02	0-300MM	0.01MM	Insize
3	Digital Vernier Caliper	DVC-03	0-150MM	0.01MM	Baker
4	Digital Vernier Caliper	DCV-04	0-150MM	0-01MM	Insize
5	Digital Vernier Caliper	DVC-05	0-150MM	0.01MM	Insize
6	Digital Vernier Caliper	DVC-06	0-150MM	0.01MM	Insize
7	Digital Vernier Caliper	DVC-07	0-150MM	0.01MM	Insize
8	Digital Vernier Caliper	DVC-08	0-200 MM	0.01MM	Baker
9	Digital Vernier Caliper	DVC-08A	0-200MM	0.01MM	Insize
10	Digital Vernier Caliper	DVC-09	0-200 MM	0.01MM	Baker
11	Digital Vernier Caliper	DVC-09A	0-200MM	0.01MM	Insize
12	Digital Vernier Caliper	DVC-10	0-200MM	0.01MM	Insize
13	Digital Vernier Caliper	DVC-10A	0-300 MM	0.01MM	Baker
14	Digimatic Inside Groove Caliper	DVC-01	25.1-175MM	0.01MM	Mitu
15	Micrometer	MM-03	25-50MM	0.001MM	Mitutoyo
16	Micrometer	MM-01	0-25MM	0.001MM	Insize
17	Micrometer	MM-02	50-75MM	0.01MM	Insize
18	Micrometer	MM-03	75-100MM	0.01MM	Insize
19	Micrometer	MM-04	0-25MM	0.01MM	Insize
20	Bevel Protector	BP-01	0°-90°-0°	5 MIN	Mita
21	Digital Height Gauge	DHG 01	0-300MM	0.01MM	Mitutoyo
22	Digital Micrometer	DMM 01	0-25MM	0.001MM	Insize
23	Digital Micrometer	DMM 02	25-50MM	0.001MM	Insize
24	Surface Roughness Tester	RT-01	0.1 to 50 µm	--	Insize
25	Digital Coating Thickness Tester	DCTG-01	0 to 1250 µm	--	Insize
26	Digital Height Gauge	DHG-02	0-300 MM	0.01MM	Baker
27	Dial Indicator	DTI 02	0-0.8MM	0.01MM	Baker
28	Granite Surface Plate	SP-01	630X630MM	--	Luthra
29	Granite Surface Plate	SP-02	630X630MM	--	Luthra
30	Granite Surface Plate	SP-02	600-630MM	--	Luthra
31	Electronic Scale		0 to 300 Kg	--	Honda
32	Pressure Gauge		0-280 Kg	--	---
33	Thread Pitch Gauge	TPG-01	Metric 60 °	--
34	Radius	RG-02	7.5-15mm	--	Garney

Machine-list

S. No	Machine	Make/Model	Qty.	Features
1	Turret Milling M/c (with accessories)	Tong Chi / Tum20VA Head	01	With 0.005 mm LC (DRO)
2	Turret Milling M/c (with accessories)	Tong Chi / Tum40VA Head	01	With 0.005 mm LC (DRO)
3	Turret Milling M/c (with accessories)	JP Mills Taiwan/ Tum-40VA Head	01	With 0.005 mm LC (DRO)
4	Vertical Milling M/C	Baljeet	01	without DRO.
5	VMC	DAHLIH (Taiwan)	01	Travel Working Area X- 1000 mm Y – 500 mm Z – 500 mm
6	Lathe M/c (with accessories)	Balaji Machines 6 Feet Head	01	1800 mm Capacity & Center Height 230mmwith DRO 0.005 mm LC
7	MILLING	HMT	01	Travel Working Area X- 2000 mm Y – 500 mm Z – 300 mm
8	Surface Grinder (with accessories)	GMT, Machino	02	9”x18” (Oil Type)
9	Drill M/c (with accessories)	Gally	01	25 mm Drill Capacity
10	Drill M/c NW 10 (with magnetic stand)	Wolf	01	31 mm Drill Size
11	Pipe Cutter M/c	Horse Power	01
12	Bench Grinder		02
13	Welding Set (Air cool type)		01
14	Genset	/40 HP	02
15	Hand Press	Unique	01	5 Tons
16	Automatic Compressor	SS System	02	2 HP Double Cylinder
17	VMC	WORLD TECH	01	Travel Working Area X- 1050 mm Y – 500 mm Z – 650 mm
18	VMC	WORLD TECH		Travel Working Area X- 850 mm Y – 550 mm Z – 550 mm
19	CNC	LMW SMART TURN - MAKE	01
